放大器

提高精度，滿足您最具挑戰性的要求

放大器系列（規格書）

CW系列：通用型連續波、脈衝和調變放大器
EMC系列：電磁相容性放大器
Pulsed系列：脈衝放大器

SKU	APPLICATION	FREQUENCY RANGE (GHZ)	PSAT (W)	CONNECTOR 1	CONNECTOR 2
MPA-0G4-12G-100	CW	0.4 to 12	100	Type N	Type N
MPA-0G4-12G-50	CW	0.4 to 12	50	Type N	Type N
MPA-0G6-6G-100	CW	0.6 to 6	100	Type N	Type N
MPA-0G6-6G-20	CW	0.6 to 6	20	SMA	SMA
MPA-0G6-6G-200	CW	0.6 to 6	200	Type N	Type N
MPA-0G6-6G-500	CW	0.6 to 6	500	Type N	7/16
MPA-0G6-6G-60	CW	0.6 to 6	60	Type N	Type N
MPA-1G-6G-1K	EMC	1 to 6	1000	Type N	7/16
MPA-1G-6G-500	EMC	1 to 6	500	Type N	7/16
MPA-1G-6G-250	EMC	1 to 6	250	Type N	Type N
MPA-18G-26G5-10	CW	18 to 26.5	10	3.5mm	3.5mm
MPA-18G-26G5-100	EMC	18 to 26.5	100	2.92mm	WR42
MPA-18G-26G5-25	CW	18 to 26.5	25	3.5mm	WR42
MPA-18G-26G5-50	EMC	18 to 26.5	50	2.92mm	WR42
MPA-18G-40G-10	CW	18 to 40	10	2.92mm	2.92mm
MPA-18G-40G-20	CW	18 to 40	20	2.92mm	WRD180C24
MPA-18G-40G-40	EMC	18 to 40	40	2.92mm	WRD180C24
MPA-26G5-40G-10	CW	26.5 to 40	10	2.92mm	2.92mm
MPA-26G5-40G-100	EMC	26.5 to 40	100	2.92mm	WR28
MPA-26G5-40G-25	CW	26.5 to 40	25	2.92mm	WR28
MPA-26G5-40G-5	CW	26.5 to 40	5	2.92mm	2.92mm
MPA-26G5-40G-50	EMC	26.5 to 40	50	2.92mm	WR28
MPA-2G-18G-20	CW	2 to 18	20	SMA	SMA
MPA-2G-18G-30	CW	2 to 18	30	SMA	SMA
MPA-2G-18G-50	CW	2 to 18	50	Type N	Type N
MPA-2G-26G5-2	CW	2 to 26.5	2	3.5mm	3.5mm
MPA-2G-6G-100	CW	2 to 6	100	Type N	Type N
MPA-2G-6G-200	CW	2 to 6	200	Type N	Type N
MPA-2G-6G-300	CW	2 to 6	300	Type N	Type N
MPA-2G-6G-600	CW	2 to 6	600	Type N	TNC
MPA-2G-8G-100	CW	2 to 8	100	Type N	Type N
MPA-2G-8G-1K	EMC	2 to 8	1000	Type N	7/16
MPA-2G-8G-50	CW	2 to 8	50	Type N	Type N
MPA-37G-43G-5	CW	37 to 43	5	2.4mm	2.4mm
MPA-40G-67G-1	CW	40 to 67	1	1.85mm	1.85mm
MPA-40G-67G-5	CW	40 to 67	5	1.85mm	1.85mm
MPA-50G-67G-5	CW	50 to 67	5	WR15	WR15
MPA-6G-18G-10	CW	6 to 18	10	SMA	SMA
MPA-6G-18G-100	CW;EMC	6 to 18	100	Type N	Type N
MPA-6G-18G-250	CW;EMC	6 to 18	250	Type N	WRD650
MPA-6G-18G-500	EMC	6 to 18	500	Type N	WRD650
MPA-6G-18G-1K	EMC	6 to 18	1000	Type N	WRD650
MPA-6G-18G-30	CW	6 to 18	30	SMA	SMA
MPA-6G-18G-50	CW;EMC	6 to 18	50	Type N	Type N
MPA-8G-12G-100	CW	8 to 12	100	Type N	Type N
MPA-6G-18G-50	CW	92 to 98	30	WR10	WR10
MPA-1G-2G-1K-P	Pulsed	1 to 2	1000	Type N	Custom
MPA-1G-2G-6K-P	Pulsed	1 to 2	6000	Type N	Custom
MPA-1G-2G-10K-P	Pulsed	1 to 2	10000	Type N	Custom
MPA-1G-4G-1K-P	Pulsed	1 to 4	1000	Type N	Custom
MPA-1G-4G-2K-P	Pulsed	1 to 4	2000	Type N	Custom
MPA-1G-4G-8K-P	Pulsed	1 to 4	8000	Type N	Custom
MPA-2G-4G-1K-P	Pulsed	2 to 4	1000	Type N	Custom
MPA-2G-4G-6K-P	Pulsed	2 to 4	6000	Type N	Custom
MPA-2G-4G-10K-P	Pulsed	2 to 4	10000	Type N	Custom
MPA-4G-8G-1K-P	Pulsed	4 to 8	1000	Type N	Custom
MPA-4G-8G-6K-P	Pulsed	4 to 8	6000	Type N	Custom
MPA-4G-8G-10K-P	Pulsed	4 to 8	10000	Type N	Custom
MPA-8G-12G-1K-P	Pulsed	8 to 12	1000	Type N	Custom
MPA-8G-12G-2K-P	Pulsed	8 to 12	2000	Type N	Custom
MPA-8G-12G-6K-P	Pulsed	8 to 12	6000	Type N	Custom
MPA-8G-12G-10K-P	Pulsed	8 to 12	10000	Type N	Custom
MPA-8G-18G-1K-P	Pulsed	8 to 18	1000	Type N	Custom
MPA-8G-18G-2K-P	Pulsed	8 to 18	2000	Type N	Custom
MPA-12G-18G-1K-P	Pulsed	12 to 18	1000	Type N	Custom
MPA-12G-18G-6K-P	Pulsed	12 to 18	6000	Type N	Custom
MPA-12G-18G-10K-P	Pulsed	12 to 18	10000	Type N	Custom
MPA-9K-400M-400	CW	9K to 0.4	400	Type N	Type N
